Description

Semi-automatic Double Head Bottle Filling Machine specifications:

Voltage: 220V.
Power: 40W.
Weight: 45kg
Filling range variants: 10ml – 100ml, 50ml – 1000ml, 1000ml – 5000ml.
Filling Accuracy: 99%.
Filling Product: Liquid, Gel & Paste.
Production rate: 5 – 60 bottles per minute.
Double filling nozzle/ head.
AirTac pneumatic components.
Machine dimensions (LxWxH): 1000 x 500 x 150mm.
Filling volume easily adjustable on spindle.
Filling speed easily adjustable on air restrictors.
Filling capacity: 5 – 50ml; 10 – 100ml; 50 – 1000ml; 1000 – 5000ml.
Air Pressure: 0,4 – 0,6 Mpa.
Can be used with a suction pipe and hopper interchangeably.
Hopper size: 30 & 40 litre.
